Principles of working
Gestito da microprocessore che ne controlla il funzionamento
e le segnalazioni, l’Inverter serie ELIT-INV è
in grado di generare una tensione alternata sinusoidale 230V
partendo da una tensione continua. La conversione è
realizzata con uno stadio di potenza a mosfet che pilota un
trasformatore elevatore a flusso disperso. Il trasformatore
svolge anche la funzione di separare galvanicamente il circuito
di ingresso da quello in uscita. La scheda di controllo genera
i segnali di pilotaggio dei mosfet, mantenendo stabile la
tensione di uscita al variare delle condizioni di carico e
di alimentazione. La scheda include anche i circuiti elettronici
che proteggono lo stadio di potenza da sovraccarichi e corto
circuiti. E’ possibile fornire l’Inverter in tre
diverse versioni: montato su ripiano in alluminio “Open
Frame”, in contenitore standard od in configurazione
rack 19”.
Technical
data
- Input voltage: 12Vdc, 24Vdc, 48Vdc and 110Vdc;
- Filtered, stabilized and regulated sine wave supply;
- Extended window input voltage;
- Insulation transformer;
- 230Vac emergency line with automatic circuit breaker as
option;
- LEDs signaling;
- Dry contacts interface to remote alarms;
- ON/OFF remote control (as option);
- Different voltages and frequencies (as request);
- Custom apparatus
|
The inverters ELIT-INV series are outcome of a long experience
in the planning and manufacturing of UPS.
The DC/AC converters distinguish themselves by advanced employed
components, and by their excellent reliability and higher
maintenance, aim characteristics of all ELIT products.
These apparatus are studied for the following main applications:
- Wind power and photovoltaic plants;
- Automation;
- Telecommunications;
- Railway field;
- Civil and military aviation;
- Civil and military shipyard.
|
|
Product
Code |
Rated
Power
VA |
Input
Voltage
Vcc |
Output
Voltage
Vca |
Configuration |
Dimensions
mm |
Weight
Kgs |
| INV12/600 |
600 |
12 |
230 |
Open frame |
420x250x160 |
8 |
| INV12/600NS |
600 |
12 |
230 |
Cabinet |
220x500x200 |
8 |
| INV12/600RT |
600 |
12 |
230 |
rack 19" |
483x300 3U |
8 |
| INV12/800 |
800 |
12 |
230 |
Open frame |
420x250x160 |
13 |
| INV 12/800NS |
800 |
12 |
230 |
Cabinet |
220x500x200 |
13 |
| INV 12/800RT |
800 |
12 |
230 |
rack 19" |
483x390 4U |
13 |
| INV12/1000 |
1000 |
12 |
230 |
Open frame |
420x250x160 |
13 |
| INV12/1000NS |
1000 |
12 |
230 |
Cabinet |
220x500x200 |
13 |
| INV12/1000RT |
1000 |
12 |
230 |
rack 19" |
483x390 4U |
13 |
Product
Code |
Rated
Power
VA |
Input
Voltage
Vcc |
Output
Voltage
Vca |
Configuration |
Dimensions
mm |
Weight
Kgs |
| INV24/500 |
500 |
24 |
230 |
Open frame |
420x250x160 |
8 |
| INV24/500NS |
500 |
24 |
230 |
Cabinet |
220x500x200 |
8 |
| INV24/500RT |
500 |
24 |
230 |
rack 19" |
483x300 3U |
8 |
| INV24/800 |
800 |
24 |
230 |
Open frame |
420x250x160 |
13 |
| INV24/800NS |
800 |
24 |
230 |
Cabinet |
220x500x200 |
13 |
| INV24/800RT |
800 |
24 |
230 |
rack 19" |
483x390 4U |
13 |
| INV24/1200 |
1200 |
24 |
230 |
Open frame |
570x310x180 |
23 |
| INV24/1200NS |
1200 |
24 |
230 |
Cabinet |
220x500x200 |
23 |
| INV24/1200RT |
1200 |
24 |
230 |
rack 19" |
483x390 4U |
23 |
| INV24/1600 |
1600 |
24 |
230 |
Open frame |
570x310x180 |
25 |
| INV24/1600NS |
1600 |
24 |
230 |
Cabinet |
215x545x550 |
25 |
| INV24/1600RT |
1600 |
24 |
230 |
rack 19" |
483x390 4U |
25 |
| INV24/2000 |
2000 |
24 |
230 |
Open frame |
570x310x180 |
28 |
| INV24/2000NS |
2000 |
24 |
230 |
Cabinet |
215x545x550 |
28 |
| INV24/2000RT |
2000 |
24 |
230 |
rack 19" |
483x390 4U |
28 |
| INV24/3000NS |
3000 |
24 |
230 |
Cabinet |
250x700x600 |
60 |
| INV24/3000RT |
3000 |
24 |
230 |
rack 19" |
483x650 5U |
60 |
| INV24/4000NS |
4000 |
24 |
230 |
Cabinet |
400x800x500 |
72 |
| INV24/4000RT |
4000 |
24 |
230 |
rack 19" |
440x650 5U |
72 |
| INV24/4500NS |
4500 |
24 |
230 |
Cabinet |
400x800x500 |
80 |
| INV24/4500RT |
4500 |
24 |
230 |
rack 19" |
440x650 5U |
80 |
Product
Code |
Rated
Power
VA |
Input
Voltage
Vcc |
Output
Voltage
Vca |
Configuration |
Dimensions
mm |
Weight
Kgs |
| INV48/500 |
500 |
48 |
230 |
Open frame |
420x250x160 |
8 |
| INV48/500NS |
500 |
48 |
230 |
Cabinet |
220x500x200 |
8 |
| INV48/500RT |
500 |
48 |
230 |
rack 19" |
483x300 3U |
8 |
| INV48/800 |
800 |
48 |
230 |
Open frame |
420x250x160 |
13 |
| INV48/800NS |
800 |
48 |
230 |
Cabinet |
220x500x200 |
13 |
| INV48/800RT |
800 |
48 |
230 |
rack 19" |
483x390 4U |
13 |
| INV48/1200 |
1200 |
48 |
230 |
Open frame |
570x310x180 |
25 |
| INV48/1200NS |
1200 |
48 |
230 |
Cabinet |
220x500x200 |
25 |
| INV48/1200RT |
1200 |
48 |
230 |
rack 19" |
483x390 4U |
25 |
| INV48/1600 |
1600 |
48 |
230 |
Open frame |
570x310x180 |
28 |
| INV48/1600NS |
1600 |
48 |
230 |
Cabinet |
215x545x550 |
28 |
| INV48/1600RT |
1600 |
48 |
230 |
rack 19" |
483x390 4U |
28 |
| INV48/2000 |
2000 |
48 |
230 |
Open frame |
570x310x180 |
35 |
| INV48/2000NS |
2000 |
48 |
230 |
Cabinet |
215x545x550 |
35 |
| INV48/2000RT |
2000 |
48 |
230 |
rack 19" |
483x390 4U |
35 |
| INV48/3000 |
3000 |
48 |
230 |
Open frame |
570x310x200 |
40 |
| INV48/3000NS |
3000 |
48 |
230 |
Cabinet |
320x605x640 |
40 |
| INV48/3000RT |
3000 |
48 |
230 |
rack 19" |
483x395 6U |
40 |
| INV48/4000 |
4000 |
48 |
230 |
Open frame |
570x310x200 |
50 |
| INV48/4000NS |
4000 |
48 |
230 |
Cabinet |
320x605x640 |
50 |
| INV48/4000RT |
4000 |
48 |
230 |
rack 19" |
483X395 6U |
50 |
| INV48/5000NS |
5000 |
48 |
230 |
Cabinet |
400x800x500 |
72 |
| INV48/5000RT |
5000 |
48 |
230 |
rack 19" |
440x650 5U |
72 |
| INV48/6000NS |
6000 |
48 |
230 |
Cabinet |
400x800x500 |
78 |
| INV48/6000RT |
6000 |
48 |
230 |
rack 19" |
440x650 5U |
78 |
Product
Code |
Rated
Power
VA |
Input
Voltage
Vcc |
Output
Voltage
Vca |
Configuration |
Dimensions
mm |
Weight
Kgs |
| INV110/500 |
500 |
110 |
230 |
Open frame |
420x250x160 |
8 |
| INV110/500NS |
500 |
110 |
230 |
Cabinet |
220x500x200 |
8 |
| INV110/500RT |
500 |
110 |
230 |
rack 19" |
483x300 3U |
8 |
| INV110/800 |
800 |
110 |
230 |
Open frame |
420x250x160 |
13 |
| INV110/800NS |
800 |
110 |
230 |
Cabinet |
215x545x550 |
13 |
| INV110/800RT |
800 |
110 |
230 |
rack 19" |
483x390 4U |
13 |
| INV110/1200 |
1200 |
110 |
230 |
Open frame |
570x310x180 |
25 |
| INV110/1200NS |
1200 |
110 |
230 |
Cabinet |
215x545x550 |
25 |
| INV110/1200RT |
1200 |
110 |
230 |
rack 19" |
483x390 4U |
25 |
| INV110/1600 |
1600 |
110 |
230 |
Open frame |
570x310x180 |
28 |
| INV110/1600NS |
1600 |
110 |
230 |
Cabinet |
215x545x550 |
28 |
| INV110/1600RT |
1600 |
110 |
230 |
rack 19" |
483x390 4U |
28 |
| INV110/2000 |
2000 |
110 |
230 |
Open frame |
570x310x180 |
35 |
| INV110/2000NS |
2000 |
110 |
230 |
Cabinet |
215x545x550 |
35 |
| INV110/2000RT |
2000 |
110 |
230 |
rack 19" |
483x390 4U |
35 |
| INV110/3000 |
3000 |
110 |
230 |
Open frame |
570x310x200 |
40 |
| INV110/3000NS |
3000 |
110 |
230 |
Cabinet |
320x605x640 |
40 |
| INV110/3000RT |
3000 |
110 |
230 |
rack 19" |
483x395 6U |
40 |
| INV110/4000NS |
4000 |
110 |
230 |
Cabinet |
250x650x600 |
66 |
| INV110/4000RT |
4000 |
110 |
230 |
rack 19" |
440x650 5U |
66 |
| INV110/5000NS |
5000 |
110 |
230 |
Cabinet |
400x800x450 |
72 |
| INV110/5000RT |
5000 |
110 |
230 |
rack 19" |
440x650 5U |
72 |
| INV110/6000NS |
6000 |
110 |
230 |
Cabinet |
400x800x450 |
78 |
| INV110/6000RT |
6000 |
110 |
230 |
rack 19" |
440x650 5U |
78 |
| INV110/7000NS |
7000 |
110 |
230 |
Cabinet |
400x800x450 |
83 |
| INV110/7000RT |
7000 |
110 |
230 |
rack 19" |
440x650 5U |
83 |
|
